The energizer powers the whole fence: wire, insulators and grounding only carry what it puts out. The right choice comes down to one figure, output joules, and four questions about your fence.
The electric fence calculator applies this method to your animal and length, suggests a recommended unit and a stronger one, and builds the complete parts list, shipped anywhere in Québec.
Output joules, stored joules and kilometres
Boxes show three figures. Distance is measured on a clean fence with no vegetation: it varies between brands and depends on soil, grass and construction. Stored joules measure the energy in the capacitor, before the transformer. Output joules measure what actually goes down the wire: always lower than stored joules, and the only figure to compare across brands (Virginia Cooperative Extension, SPES-689P).
Gallagher example: the M160 stores 1.6 J and puts out 0.86 J. Gallagher model numbers follow stored joules, not output joules.
The rule: one output joule per mile of fence
A good guideline is one output joule per mile (1.6 km) of fence, as long as the live wires are joined at the start and end of each run: then adding wires does not require more joules (Virginia Cooperative Extension, SPES-689P). The same rule applies to every animal; what changes with the animal is wire height and the voltage to read.
The same guide often advises buying a larger unit than needed: tall grass in July, frozen ground in winter and a fence you will extend later all draw on the reserve. That is why the calculator offers two units: the lowest-priced one in stock that meets the need, and a stronger one.
Example: a 10-acre (about 4 ha) cattle pasture has a perimeter of about 805 m. Need: 0.805 km ÷ 1.6 = 0.5 J of output. The Gallagher M160 (0.86 J output) meets it; the MB150 (1.16 J output, mains or battery) gives more headroom.
The four questions
- Which animal? It sets the height and number of wires, and the minimum voltage to read on the fence.
- What length? The fence perimeter, in metres. Join the live wires together at the start, the end and every 400 m.
- What vegetation? Grass touching the wire leaks current; the more there is, the more the stronger unit makes sense.
- What power source? A 120 V outlet, a battery or a solar panel.
Wire heights and voltage by animal
| Animal | Wires and heights from the ground | Minimum voltage on the fence |
|---|---|---|
| Cattle | 3 wires: 46, 76, 107 cm | 2,000 V |
| Cows and calves (perimeter) | 5 wires: 25, 51, 76, 102, 127 cm | 2,000 V |
| Horses | 5 wires: 46, 69, 91, 114, 137 cm | 2,000 V |
| Sheep | 5 wires: 15, 30, 45, 65, 90 cm | 2,000 V |
| Goats | 5 wires: 15, 30, 46, 71, 97 cm | 3,000 V |
| Pigs | 3 wires: 20, 46, 66 cm | 2,000 V |
| Deer (garden) | 2 wires: 46, 91 cm | 5,000 V |
| Raccoons | 2 wires: 15, 30 cm | 5,000 V |
Sources: Virginia Cooperative Extension SPES-688P, USDA NRCS Iowa, AHDB, University of Missouri Extension (MP685, G9453), Gallagher Electric Fencing 101 (pigs), Parmak installation manual 2025. For horses and pigs, the Parmak manual gives 1,000 V for animals trained to electric fencing; we aim for 2,000 V, as for cattle. The Parmak manual sums it up: one live wire at about two thirds of the height of each size of animal in the field.
Mains, battery or solar
If an outlet is within reach, mains gives the most output joules for the price (SPES-689P) and needs no battery upkeep. A battery should last about three weeks between charges (USDA NRCS Iowa). Solar suits a distant field or rotational grazing; in winter, short days and snow on the panel cut charging, so keep headroom if the fence must run all year.
Grounding
Current returns to the energizer through the soil: without good grounding, even a large unit gives a weak shock. For energizers up to 15 stored joules, Gallagher calls for at least three galvanized rods of 1.8 m (6 ft), 3 m (10 ft) apart, joined by one cable, with a clamp per rod (Gallagher, Electric Fencing 101). A low-output portable battery or solar unit needs one ground stake driven at least 60 cm (Gallagher S20 manual); an energizer on an outlet needs the fixed rods, even on a temporary fence. Frozen or dry soil conducts poorly: add rods or a ground-return wire.
- Galvanized ground rod 1.8 m, Gallagher
- T ground rod 90 cm, Gallagher (portable unit)
- Sentinel ground clamp
- Sentinel lightning diverter kit: its own ground, at least 20 m from the energizer’s (USDA NRCS Iowa)

Energizers in stock
Gallagher publishes output joules for most of its models, so they can be compared with the rule above: see the Gallagher energizers. Parmak publishes two figures, high and low joules, without saying whether they are stored or output joules; the calculator derives a conservative output estimate from them so both brands are compared on the same rule.
Check
After installing, read the voltage at the far end of the fence with a voltage indicator. Per Parmak, the energizer alone should give about 5,000 V or more; below 2,000 V on the fence, look for a leak or poor grounding.
Work out my complete system. A question? Write to us or call 450-263-2008.
